2580 Conformal Coating for circuit board protection of household electrical products

Product Properties

Conformal Coating

Viscosity:30-100MPas
Heat resistance: good curing mode: humidity and temperature double curing
Function: anti-leakage, anticorrosion, moisture-proof, dust-proof
Use: electronic components three defense
Features:Customizable
Not a dangerous chemical

Features and parameters

2582 Low odor, free of toxic and benzene solvents, thin coat process, 50% solids
2583-V Low odor, free of toxic and benzene solvents, thin coating process, 52% solids.
Good ageing resistance
2583-H Low odor, free of toxic and benzene solvents, thin coating process, 45% solids.
High elasticity and good abrasion resistance

Model:2580/2582/2582-V/2582-H
Color:transparent/translucent
guangzhou excellence chemical technology co.
Viscosity(mpas):(30-100)
Surface drying time(min):10min
Heating curing time(min):10-15min
Complete curing time(h):24h
Dielectric constant(1MHz):2.7/3.5
Breakdown voltage(KV/mm):≥15
Operating Temperature(°C):-40-220
Hundred grams test grade: 5B
Double 85 Test:Pass
Repairability:Pass
Density(g/cm3):0.85

Scope of application

This product is widely used in washing machines, outdoor electronic LED screens, monitors, air conditioners, dryers, computers, induction cookers, medical and military industries, etc. that require triple protection.display, air conditioner, dryer, computer, induction cooker, medical, military, etc., which need three-proof protection of circuit boards that need three-proof protection.
